Evolving Neural Networks in TypeScript

Introducing @neat-evolution, a modular implementation of NEAT in TypeScript.

I’ve been sitting on this for quite a while. After months of development, I’m excited to finally introduce @neat-evolution, a modular implementation of the NEAT (NeuroEvolution of Augmenting Topologies) algorithm in TypeScript. This was based on des-hyperneat, a Rust implementation of NEAT. I was drawn to the project because I wanted to experiment with evolving neural networks in a language I was more comfortable with.

I was impressed by how the original Rust implementation composed the various flavors of the NEAT algorithm in a modular fashion. This inspired me to create a TypeScript version that could be easily integrated into web applications and other TypeScript projects.

The resulting code appears to work well but it’s not yet battle-tested. I have since moved on to other projects but I wanted to share this work to document it and make it available to others who might find it useful.

What is NEAT?

If you aren’t familiar, NEAT is a genetic algorithm for evolving neural networks. There have been many popular YouTube videos, which is where I first heard about it many years ago. Here’s a video where someone uses NEAT to play Asteroids.

If you’re wondering why you haven’t heard of this or why it’s not more widely used, it’s because NEAT is primarily a research algorithm. While it has some interesting properties, it hasn’t seen widespread adoption in production systems. However, it’s a fascinating area of study for those interested in evolutionary algorithms and neural networks.

Why I Built It

I was originally interested in developing this library to play the Asteroids-style game, Hexagonoids, that I built a while back. My goal was to evolve neural networks that could effectively play the game using the NEAT algorithm. I never got around to it.

I also pursued this project because I was not happy with the NEAT implementations available. I had read about more advanced implementations, like ES-Hyperneat, that had been developed by the inventor of NEAT but were not available in the existing JS implementations.

This was also a good opportunity for me to explore good code management best practices, utilizing a Yarn Monorepo for managing the code as separate packages, and GitHub Actions for automatically versioning and publishing the code to the GitHub Package Registry. To that end, I implemented a fully automated package release workflow using Beachball.

Parallel Processing

I spent a significant amount of time focusing on performance. Obviously Rust is known for being much faster than TypeScript. However, after some significant tweaking, my TypeScript implementation was just as fast as the Rust version on my machine. To be fair, the Rust version was not heavily optimized, but I was still pleased with the results.

The original Rust implementation used threads for a portion of the algorithm, and I was able to implement that in a cross-platform manner using Node Worker Threads and Web Workers based on the environment. I created the @neat-evolution/worker-threads package to transparently switch to the correct worker implementation using conditional exports.

Interestingly, I noticed some parts of the Rust implementation that could have been parallelized but weren’t. The original implementation was intended for academic purposes and was never fully optimized.

If you aren’t aware, NEAT evolves a population of neural networks and then selects the best network after each generation. Most implementations use a default of 100 “genomes” grouped into species, which means that it can be quite computationally expensive as you need to evaluate 100 neural networks at each training step. By contrast, training a neural network with something like TensorFlow evaluates only one network at a time.

I was able to move all of the evaluation and reproduction steps into workers, which ended up making my implementation quite fast as it can use all of the CPU cores available, even in the browser.

Memory Leaks

Once I had the full library implemented, I noticed it was not able to run for very long without crashing. Upon inspection, it was because the original implementation kept a registry of each link in the neural network that had ever been created. This is part of the NEAT algorithm and is intended as a way to track “innovation” in the population of neural networks, where the links between nodes in the network function as the “genome”. This was especially pronounced when running DES-Hyperneat, which is like a nested application of NEAT algorithms where each node is itself an independent NEAT network. This ended up ballooning the registry as many more connections were added, and the registry grew quite large.

I ended up replacing the registry altogether for a custom solution that used names on the nodes to solve the same issue. This was much faster but doesn’t follow the original implementation of NEAT and might not perfectly match what the registry system was providing. My testing didn’t uncover any noticeable differences. The result was much faster performance and much lower memory overhead. This was particularly helpful with regards to using worker threads, as the registry context no longer needed to be shared between the main thread and all of the workers.

Other Performance Tweaks

Use for Loops

One of the biggest performance tweaks was avoiding built-in array looping functions like Array.map or Array.some. In a normal web application, it doesn’t matter, but there is a tiny overhead involved in creating and executing an arrow function. In all cases where looping is required, using a traditional for loop is faster, if only by that tiny amount. In the case of NEAT, where we constantly are looping over an arrays of 100 neural networks and then looping over all of the nodes, that tiny difference is magnified, and this kind of micro-optimization is worth the hassle.

Use Generators

This is most evident in the Population class where most of the work is done. There are numerous times when we need to iterate over a set of objects, and in each of those times, we rely on iterators (often async iterators) to reduce the performance hit of creating temporary arrays. This allows us to more efficiently pass the streaming output from, say, a worker pool that is processing every Genome in the population directly into a loop, which saves memory and processing time.

*genomeEntries(): IterableIterator<GenomeEntry<G>> {
	for (const [speciesIndex, species] of this.species.entries()) {
		for (const [organismIndex, { genome }] of species.organismEntries()) {
			yield [speciesIndex, organismIndex, genome]
		}
	}
}

Use Map and QuickLRU

Whenever we need to keep a collection of objects, it’s always better to use a Map instead of a plain object. Whenever a Map might grow out of control, use QuickLRU to prevent any possibility of memory leak. You do need to make sure that any data the QuickLRU might discard is not useful or could easily be recalculated.

this.species = new Map<number, Species<CD, SD, HND, LD, GFO, GO, G>>();

// extinct species are only used for reporting
this.extinctSpecies = new QuickLRU<
  number,
  Species<CD, SD, HND, LD, GFO, GO, G>
>({ maxSize: 1000 });

Translation Challenges

The greatest challenge was translating from Rust to TypeScript. I heavily relied on ChatGPT for this, as I did not know Rust. I developed a workflow where I would paste each Rust file into ChatGPT and ask it to translate it to TypeScript. This was surprisingly effective but far from perfect. The final code in the project today is very different from what ChatGPT produced, but the initial translation was automated.

Some things ported over quite well. Some things did not.

In all cases, Rust is strongly typed, which is a great advantage as the code is easy to trace, and the resulting TypeScript code is also well typed. However, in all cases, TypeScript is loosely typed. TypeScript gives you plenty of escape hatches to mutate the types.

TypeScript classes are not simply Rust struct and impl

Rust does not have classes in the same way that TypeScript does. Instead, the components of a class are split up between structs (conceptually similar to class properties) and implementations (conceptually similar to class methods). In many cases, glueing the struct and implementation together into a single TypeScript class will work just fine, and that’s mostly what was done in the translation process. However, Rust is very expressive and allows for a kind of context-aware inheritance that is impossible to recreate in TypeScript.

The original Rust source code used many clever techniques that allowed them to compose the various NEAT algorithms from the basic building blocks. For instance, the NEAT algorithm could be extended to support Hyperneat and ES-Hyperneat, and the Population can adapt to the needs of these different algorithms. Most of the functionality is the same, but different traits enable different capabilities based on the context.

Rust is really powerful. TypeScript is not. This led to many hours of tracing the Rust code in circles to unpack what was really happening and making adjustments to the TypeScript classes to accommodate that. The most obvious side effect is that all of this dependency injection needed to be represented in TypeScript’s woefully underpowered type system… and some of the types got HUGE.

Rust

Rust is able to fill in the blanks because it is fully context-aware. The population might be a Genome of any NEAT variant, and Rust can figure that out based on the context.

pub struct Population<G: Genome> {
	// ...
}

impl<G: Genome> Population<G> {
	// ...
}

TypeScript

TypeScript has no idea what’s going on, so you have to tell it about all possible use cases. It’s possible this could be simplified, but the extensible nature of the source implementation means that TypeScript isn’t sure what it’s dealing with unless you are explicit.

export class Population<
  // Genome
  CFO extends ConfigFactoryOptions,
  NCO extends ConfigOptions,
  LCO extends ConfigOptions,
  CD extends ConfigData,
  C extends CoreConfig<CFO, NCO, LCO, CD>,
  NSD,
  LSD,
  NS extends ExtendedState<NSD>,
  LS extends ExtendedState<LSD>,
  SD extends StateData,
  S extends CoreState<NSD, LSD, NS, LS, SD>,
  HND,
  LD,
  GFO extends GenomeFactoryOptions<HND, LD>,
  GO extends GenomeOptions,
  GD extends GenomeData<CD, SD, HND, LD, GFO, GO>,
  // CoreNode
  NFO extends NodeFactoryOptions,
  N extends CoreNode<NFO, NCO, NSD, NS, N>,
  // CoreLink
  LFO extends LinkFactoryOptions,
  L extends CoreLink<LFO, LCO, LSD, LS, L>,
  // CoreGenome
  G extends CoreGenome<
    CFO,
    NCO,
    LCO,
    CD,
    C,
    NSD,
    LSD,
    NS,
    LS,
    SD,
    S,
    HND,
    LD,
    GFO,
    GO,
    GD,
    NFO,
    N,
    LFO,
    L,
    G
  >,
  // Algorithm
  A extends Algorithm<
    CFO,
    NCO,
    LCO,
    CD,
    C,
    NSD,
    LSD,
    NS,
    LS,
    SD,
    S,
    HND,
    LD,
    GFO,
    GO,
    GD,
    NFO,
    N,
    LFO,
    L,
    G
  >,
> {
  // ...
}

Extensibility Versus Usability

The original source code was designed to be extendible so that you could swap out key components of the algorithm quickly, which suited the experimental needs of the original implementer. This is a feature that I found quite compelling. The final TypeScript code builds on that extensible base, and it is possible to, for instance, replace the async WorkerEvaluator with an imaginary RESTEvaluator to move the evaluation of populations to a backend service. You could also replace the default DatasetEnvironment with an imaginary GameEnvironment that gets data from a game state instead of a CSV file.

The downside to all of this extensibility is that it’s not very easy to use this library without fully understanding how all of it works.

The upside is that if you wanted to actually use this in your project, you might redefine key aspects of the system, such as your training environment (maybe a DatabaseEnvironment or a RESTEnvironment) and how your population is evaluated. These hooks are crucial for using NEAT for any practical purposes but obviously poses a huge barrier to entry.

Barebones Example

Here you can see a barebones example of running the plain NEAT algorithm with all default options.

import { defaultNEATConfigOptions } from "@neat-evolution/core";
import {
  DatasetEnvironment,
  defaultDatasetOptions,
  loadDataset,
} from "@neat-evolution/dataset-environment";
import { createEvaluator } from "@neat-evolution/evaluator";
import {
  createReproducer,
  defaultEvolutionOptions,
  defaultPopulationOptions,
} from "@neat-evolution/evolution";
import {
  defaultNEATGenomeOptions,
  neat,
  NEATAlgorithm,
} from "@neat-evolution/neat";

async function runNeatExample() {
  // 1. Setup the environment (e.g., a dataset environment)

  const datasetOptions = {
    ...defaultDatasetOptions,
    dataset: "./path/to/your/dataset.txt",
  };

  const dataset = await loadDataset(datasetOptions);

  const environment = new DatasetEnvironment(dataset);

  // 2. Create an evaluator

  const evaluator = createEvaluator(NEATAlgorithm, environment, null); // null for executor if not needed directly

  // 3. Define evolution options

  const evolutionOptions = { ...defaultEvolutionOptions, iterations: 100 };

  // 4. Define NEAT-specific configuration

  const neatConfigOptions = { ...defaultNEATConfigOptions };

  // 5. Define population options

  const populationOptions = { ...defaultPopulationOptions };

  // 6. Define genome options

  const genomeOptions = { ...defaultNEATGenomeOptions };

  // 7. Run the NEAT algorithm

  const bestGenome = await neat(
    createReproducer,
    evaluator,
    evolutionOptions,
    neatConfigOptions,
    populationOptions,
    genomeOptions,
  );

  console.log("Best genome found:", bestGenome);
}

runNeatExample();

Conclusion

I’ve paused my work on this project and likely won’t pick it up again. I was able to get it working on the most basic examples, but I was never quite convinced that I didn’t make some minor mistake deep in the code somewhere that caused it to have trouble training. I spent many hours stepping through a running application with a debugger to double-check that the TypeScript version was working the same as the Rust version. Eventually, I decided that it’s virtually impossible to verify given the random nature of the NEAT algorithm and the various differences in how Rust and TypeScript deal with numbers.

I had begun working on a Tic Tac Toe demo, and I was able to get it to train, even in the browser. However, it was objectively terrible at Tic Tac Toe and would make the same mistakes over and over, no matter how long it was allowed to train. This is quite possibly an error in my training methodology or an error deep in my implementation.

It’s also possible that there are errors in the source implementation that I have faithfully ported over to TypeScript. Even after all of this, I’m not enough of an expert in NEAT to really know for sure. The original papers are pretty vague on the particulars. There is a well-known Python implementation of NEAT that could be used to comparison test, but I have not done this.

That said, this was a really fun project and totally scratched an itch. For many years, I’d been thinking about the NEAT algorithm, as it seemed like a far superior solution to hand-crafting a neural network using TensorFlow. Numerous times I’d started a weekend project to experiment with NEAT and hit roadblocks, such as the existing solutions not being very extensible or the best solutions all being in Python. Now I know for sure that NEAT is not a panacea and, while it’s still a very cool concept, it’s not something I need to think about any more.
